MCX/MMCX Connector, MMCX Right-Angle Plug (three-piece set), KH-MCX-K506-Z
Benefits:Right-Angle Configuration: Saves space and reduces cable strain by allowing connections in
Characteristic impedance: 50Ω
Rated current: 0-18GHz
Dielectrically withstanding voltage: 1000VRMS
Voltage rating: 335 VRMS
Insulation Resistance:>5000MΩ
Benefits:
Right-Angle Configuration: Saves space and reduces cable strain by allowing connections in tight or constrained areas.
High Compatibility: Suitable for various MCX and MMCX applications, enhancing versatility.
Reliable Signal Integrity: Ensures consistent and clear signal transmission with minimal loss.
Robust Design: Built to withstand physical stress and provide long-term durability.
Applications:
Compact Electronics: Ideal for devices where space is limited, like small wireless gadgets.
Consumer Devices: Used in portable electronics such as handheld radios and GPS units.
Networking Gear: Connects components in tight spaces within networking devices.
Testing Equipment: Facilitates precise RF measurements in laboratory and diagnostic setups.
Name
Title
Description
Datasheet
Support
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
Related Products
132194 Amphenol Benchmark Against--Kinghelm MCX/MMCX Connector KH-MCX-K507-W
品牌： kinghelm， Product： KH-MCX-K506-Z Category： RF Connector Type： Plug Mounting Style： Through hole Product： KH-MCX-K506-Z Category： MCX Cable Connector
