SMA Male Plug To SMA Male Plug, RG1.13,160mm,KH-SMAJ-221-RG1.13-B160

Product Description:Electrical Specifications:●Voltage Rating: The cable is designed to withstand DC

Brand: Kinghelm

Model: KH-SMAJ-221-RG1.13-B160

Gross Weight: 3.74 grams

Package: Bag packaging

Download Datasheet Online Consultation

Product Details Product Documents Technical Support

Product Description:

Electrical Specifications:

●Voltage Rating: The cable is designed to withstand DC 300V for 10 milliseconds, ensuring reliable performance under specified voltage conditions.

●Conductance Resistance: The cable has a maximum conductance resistance of 3.0 ohms, facilitating efficient electrical conduction and minimizing energy loss.

●Insulation Resistance: With a minimum insulation resistance of 5.0 megaohms per meter, the cable provides excellent protection against leakage currents and reduces the risk of short circuits.

●Quality Assurance: The cable undergoes 100% electrical testing to guarantee its quality and reliability. This testing process ensures that the cable meets the specified electrical standards and operates without any open circuit, short circuit, miswiring, or intermittent failures.

Material:

●Please refer to the provided table for detailed information on the materials used in the cable assembly. Each material is selected for its quality, durability, and suitability for the intended application.

Compliance:

●RoHS Compliant: All components utilized in this product adhere to RoHS regulations, demonstrating our commitment to environmental responsibility and safe manufacturing practices.

Key Features:

●Robust Electrical Performance: The cable assembly delivers consistent and reliable performance under varying electrical conditions, meeting the requirements of demanding applications.

●Efficient Conduction: With low conductance resistance, the cable ensures efficient transmission of electrical signals with minimal energy loss.

●Enhanced Safety: The high insulation resistance of the cable provides a secure barrier against leakage currents and potential short circuits, enhancing overall safety.

Quality Assurance:

●The cable assembly is meticulously tested for electrical performance to ensure it meets the specified standards and functions flawlessly without any issues like open circuit, short circuit, miswiring, or intermittent failures.

●Compliance with RoHS regulations underscores our dedication to sustainability and environmentally friendly practices in manufacturing.
