SMA Male Plug To SMA Male Plug, RG1.37,100mm,KH-SMAJ-221-RG1.37-B100

Product Description:1. Electrical Specifications:●Voltage Rating: Operating at a DC voltage rating o

Brand: Kinghelm

Model: KH-SMAJ-221-RG1.37-B100

Gross Weight: 3.47 grams

Package: Bag packaging

Download Datasheet Online Consultation

Product Details Product Documents Technical Support

Product Description:

1. Electrical Specifications:

●Voltage Rating: Operating at a DC voltage rating of 300V for durations of up to 10 milliseconds, this cable is suitable for applications requiring brief high-voltage tolerance.

●Conductance Resistance: With a maximum conductance resistance of 3.0 ohms per meter, this cable ensures efficient electrical conductivity while minimizing power loss over extended distances.

●Insulation Resistance: Featuring a minimum insulation resistance of 5.0 megaohms per meter, the cable provides robust protection against electrical leakage for reliable performance in various operating conditions.

●Quality Assurance: Each cable undergoes a rigorous 100% electrical test to validate its integrity, ensuring consistent and dependable performance in real-world applications.

●Reliability: The cable is free from any open/short circuits, miswiring, or intermittent failures, guaranteeing a secure and reliable electrical connection.

2. Material Specifications:

●Composition: Refer to the detailed material composition provided in the accompanying table for information on the materials used in the construction of this cable.

3. Compliance:

●RoHS Compliance: All components utilized in the cable adhere to the Restriction of Hazardous Substances (RoHS) directive, affirming our dedication to environmental responsibility and compliance with regulatory standards.
