SMA Male Plug To SMA Male Plug, RG1.78 Cable,70mm,KH-SMAJ-221-RG1.78-70

Product Description:Electrical Specifications:●Voltage Rating: The cable is rated for DC 300V for du

Brand: Kinghelm

Model: KH-SMAJ-221-RG1.78-70

Gross Weight: 3.73 grams

Package: Bag packaging

Download Datasheet Online Consultation

Product Details Product Documents Technical Support

Product Description:

Electrical Specifications:

●Voltage Rating: The cable is rated for DC 300V for durations of up to 10 milliseconds, suitable for applications requiring short-term high-voltage tolerance.

●Conductance Resistance: With a maximum conductance resistance of 3.0 ohms per meter, the cable ensures efficient electrical conductivity and minimizes power loss over distances.

●Insulation Resistance: Providing a minimum insulation resistance of 5.0 megaohms per meter, the cable offers reliable performance and protection against electrical leakage.

●Quality Assurance: Each cable undergoes a thorough 100% electrical test to verify integrity and functionality, ensuring consistent and dependable performance.

●Reliability: Designed to be free from any open/short circuits, miswiring, and intermittent failures, guaranteeing a secure and reliable electrical connection.

Material Specifications:

●Composition: Please refer to the provided table for detailed information on the materials used in the cable's construction.

Compliance:

●RoHS Compliance: All components within the cable are compliant with RoHS standards, showcasing adherence to environmental regulations and safety standards

Name

Title

Description

KH-SMAJ-221-RG1.78-70.pdf

KH-SMAJ-221-RG1.78-70

Datasheet

Support

Support

If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.

Longevity

The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
