SMA Male Plug To SMA Male Plug, RG1.13,200mm,KH-SMAJ-221-RG1.13-B200

Product Description:Electrical Specifications:●Voltage Rating: The cable is designed to operate with

Brand: Kinghelm

Model: KH-SMAJ-221-RG1.13-B200

Gross Weight: 3.85 grams

Package: Bag packaging

Download Datasheet Online Consultation

Product Details Product Documents Technical Support

Product Description:

Electrical Specifications:

●Voltage Rating: The cable is designed to operate within a voltage range of DC 300V for 10 milliseconds, ensuring reliable performance under specified voltage conditions.

●Conductance Resistance: The cable exhibits a maximum conductance resistance of 3.0 ohms, facilitating efficient electrical conduction and minimizing energy loss.

●Insulation Resistance: With a minimum insulation resistance of 5.0 megaohms per meter, the cable provides excellent protection against leakage currents and reduces the risk of short circuits.

●Quality Assurance: The cable undergoes 100% electrical testing to guarantee its quality and reliability. This testing process ensures that the cable meets the specified electrical standards and operates without any open circuit, short circuit, miswiring, or intermittent failures.

Material:

●Please refer to the provided table for detailed information on the materials used in the cable assembly. Each material is selected for its quality, durability, and suitability for the intended application.

Compliance:

●RoHS Compliant: All components utilized in this product adhere to RoHS regulations, demonstrating our commitment to environmental responsibility and safe manufacturing practices.
