SMA Male Plug To SMA Male Plug, RG1.13,250mm,KH-SMAJ-221-RG1.13-B250

Product Description:Electrical Specifications:●Voltage Rating: DC 300V for 10ms - The cable is desig

Brand: Kinghelm

Model: KH-SMAJ-221-RG1.13-B250

Gross Weight: 3.99 grams

Package: Bag packaging

Download Datasheet Online Consultation

Product Details Product Documents Technical Support

Product Description:

Electrical Specifications:

●Voltage Rating: DC 300V for 10ms - The cable is designed to withstand a maximum voltage of 300V DC for 10 milliseconds, ensuring safe and reliable operation within this range.

●Conductance Resistance: Maximum 3.0 ohms - The cable's conductance resistance does not exceed 3.0 ohms, allowing for efficient electrical conduction and minimal energy loss.

●Insulation Resistance: Minimum 5.0M ohms - The cable has a minimum insulation resistance of 5.0 megaohms, providing effective insulation to prevent leakage currents and reduce the risk of short circuits.

●Testing Requirement: The cable undergoes 100% electrical testing to verify its performance and quality, ensuring compliance with specified standards and reliability in operation.

●Quality Assurance: The cable is guaranteed to have no open circuits, short circuits, miswiring, or intermittent failures, meeting high-quality standards for safe and consistent electrical performance.

Material:

●Please refer to the accompanying table for detailed information on the materials used in the cable assembly. Each material is carefully selected to meet the required specifications for durability, conductivity, and safety.

Compliance:

●All components used in the production of this cable assembly are compliant with RoHS regulations, demonstrating our commitment to environmental protection and the use of safe, sustainable materials.
