SMA Male Plug To SMA Male Plug, RG1.37,250mm,KH-SMAJ-221-RG1.37-B250

Product Description:1. Electrical Specifications:1.1 Voltage Rating: The cable is designed to operat

Brand: Kinghelm

Model: KH-SMAJ-221-RG1.37-B250

Gross Weight: 4.38 grams

Package: Bag packaging

Download Datasheet Online Consultation

Product Details Product Documents Technical Support

Product Description:

1. Electrical Specifications:

1.1 Voltage Rating: The cable is designed to operate at a maximum voltage rating of DC 300V for durations of up to 10 milliseconds, making it suitable for applications that require brief high-voltage tolerance.

1.2 Conductance Resistance: With a maximum conductance resistance of 3.0 ohms per meter, this cable ensures efficient electrical conductivity while minimizing power loss over extended distances.

1.3 Insulation Resistance: The cable offers a minimum insulation resistance of 5.0 megaohms per meter, providing robust protection against electrical leakage and ensuring reliable performance in various operating conditions.

1.4 Quality Assurance: Each cable undergoes a comprehensive 100% electrical test to ensure its integrity and functionality, guaranteeing consistent and dependable performance in real-world applications.

1.5 Reliability: The cable is designed to be free from any open/short circuits, miswiring, and intermittent failures, ensuring a secure and reliable electrical connection.

2. Material Specifications:

2.1 Composition: Please refer to the accompanying table for detailed information on the materials used in the construction of this cable.

3. Compliance:

3.1 RoHS Compliance: All components utilized in the cable are compliant with the Restriction of Hazardous Substances (RoHS) directive, demonstrating our commitment to environmental sustainability and adherence to regulatory standards.
