Home Product Categories RF Connector & Cable Jumper Series RF Cable RG178 Jumper Cable

Show 3D Model

SMA Male Plug To SMA Male Plug, RG1.78 Cable,100mm,KH-SMAJ-221-RG1.78-100

Product Description:1. Electrical Specifications:●Voltage Rating: The cable is rated for DC 300V wit

Brand: Kinghelm

Model: KH-SMAJ-221-RG1.78-100

Gross Weight: 3.97 grams

Package: Bag packaging

Download Datasheet Online Consultation

Product Details Product Documents Technical Support

Product Description:

1. Electrical Specifications:

●Voltage Rating: The cable is rated for DC 300V with a tolerance for durations of up to 10 milliseconds, providing suitability for applications requiring short-term high-voltage resistance.

●Conductance Resistance: With a maximum conductance resistance of 3.0 ohms per meter, the cable ensures efficient electrical conductivity and minimizes power loss over distance.

●Insulation Resistance: The cable offers a minimum insulation resistance of 5.0 megaohms per meter, ensuring reliable performance and protection against electrical leakage.

●Quality Assurance: Each cable undergoes a comprehensive 100% electrical test, validating its integrity and functionality, ensuring consistent and dependable performance.

●Reliability: The cable is designed to be free from any open/short circuits, miswiring, and intermittent failures, guaranteeing a secure and reliable electrical connection.

2. Material Specifications:

●Composition: Please refer to the provided table for detailed information on the materials used in the construction of the cable.

3. Compliance:

●RoHS Compliance: All components within the cable are compliant with RoHS standards, demonstrating adherence to environmental regulations and safety standards.

Name

Title

Description

KH-SMAJ-221-RG1.78-100.pdf

KH-SMAJ-221-RG1.78-100

Datasheet
