SMA Male Plug To SMA Male Plug, RG1.78 Cable,250mm,KH-SMAJ-221-RG1.78-250

Product Description:Electrical Specifications:Voltage Rating: The cable is rated for DC 300V with a

Brand: Kinghelm

Model: KH-SMAJ-221-RG1.78-250

Gross Weight: 5.14 grams

Package:Bag packaging

Download Datasheet Online Consultation

Product Details Product Documents Technical Support

Product Description:

Electrical Specifications:

Voltage Rating: The cable is rated for DC 300V with a tolerance for durations of up to 10 milliseconds, making it suitable for applications requiring short-term high-voltage resistance.

Conductance Resistance: The cable has a maximum conductance resistance of 3.0 ohms per meter, ensuring efficient electrical conductivity and minimizing power loss.

Insulation Resistance: With a minimum insulation resistance of 5.0 megaohms per meter, the cable provides reliable performance and protection against electrical leakage.

Quality Assurance: Each cable undergoes a 100% electrical test to verify its functionality and integrity, ensuring high quality.

Reliability: The cable is designed to be free from any open/short circuits, miswiring, and intermittent failures, guaranteeing a stable electrical connection.

Material Specifications:

Composition: Please refer to the provided table for detailed information on the materials used in the construction of the cable.

Compliance:

RoHS Compliance: All components within the cable adhere to RoHS compliance standards, demonstrating a commitment to environmental sustainability and safety regulations.
