SMA Male Plug To SMA Male Plug, RG1.78 Cable,300mm,KH-SMAJ-221-RG1.78-300

Product Description:1. Electrical Specifications:●Voltage Rating: The cable is rated for DC 300V wit

Brand: Kinghelm

Model: KH-SMAJ-221-RG1.78-300

Gross Weight: 5.55 grams

Package:Bag packaging

Download Datasheet Online Consultation

Product Details Product Documents Technical Support

Product Description:

1. Electrical Specifications:

●Voltage Rating: The cable is rated for DC 300V with a tolerance for durations of up to 10 milliseconds, making it suitable for applications requiring short-term high-voltage resistance.

●Conductance Resistance: The cable has a maximum conductance resistance of 3.0 ohms per meter, ensuring efficient electrical conductivity and minimizing power loss.

●Insulation Resistance: With a minimum insulation resistance of 5.0 megaohms per meter, the cable provides reliable performance and protection against electrical leakage.

●Quality Assurance: Each cable undergoes a 100% electrical test to ensure its functionality and integrity, meeting stringent quality standards.

●Reliability: The cable is designed to be free from any open/short circuits, miswiring, and intermittent failures, ensuring a stable and secure electrical connection.

2. Material Specifications:

●Composition: Please refer to the provided table for detailed information on the materials used in the construction of the cable.

3. Compliance:

●RoHS Compliance: All components within the cable are compliant with RoHS regulations, reflecting a commitment to environmental sustainability and safety standards.

Name

Title

Description

KH-SMAJ-221-RG1.78-300.pdf

KH-SMAJ-221-RG1.78-300

Datasheet
