IDC Connector, 2.54mm Pitch, 5-Pin, 2-Row, KH-2.54PH180-2X5P-L8.9
Product Benefits● 2.54mm pitch, 5-pin, 2-row layout● 180° straight insertion● Gold flash plating for
Current Rating: 3A
Insulation Resistance: 5000 MΩ Min
Dielectric Withstanding Voltage: AC 500V
Operating Temperature: -40℃ to +105℃
Insulator Material: PBT
Contact Plating: Gold Flash
Product Benefits
● 2.54mm pitch, 5-pin, 2-row layout
● 180° straight insertion
● Gold flash plating for reliable conductivity
● Durable PBT insulator
● Wide temperature range (-40℃ to +105℃)
Product Application
● IDC cable connections
● Industrial and consumer electronics
● Embedded systems
● Signal transmission
