IDC Connector, 2.54mm Pitch, 20-Pin, 2-Row, KH-2.54PH180-2X20P-L8.9
Product Benefits● 2.54mm pitch with 2-row 20-pin configuration● 180° straight insertion for standard
Current Rating: 3A
Insulation Resistance: 5000 MΩ Min
Dielectric Withstanding Voltage: AC 500V
Operating Temperature: -40℃ to +105℃
Insulator Material: PBT
Contact Plating: Gold Flash
Product Benefits
● 2.54mm pitch with 2-row 20-pin configuration
● 180° straight insertion for standard PCB layouts
● Gold flash plating for reliable electrical contact
● Durable PBT housing for thermal and mechanical stability
● Wide operating temperature range (-40℃ to +105℃)
Product Application
● IDC cable-to-board connections
● Industrial control and automation
● Consumer electronics
● Communication equipment
● Embedded system interfaces
