IDC Connector, 2.54mm Pitch, 9-Pin, 2-Row, KH-2.54PH180-2X9P-L8.9
Product Benefits● 2.54mm pitch with 180° straight insertion● 8.9mm insulator height for stable mount
Current Rating: 3A
Insulation Resistance: 5000 MΩ Min
Dielectric Withstanding Voltage: AC 500V
Operating Temperature: -40℃ to +105℃
Insulator Material: PBT
Contact Plating: Gold Flash
Product Benefits
● 2.54mm pitch with 180° straight insertion
● 8.9mm insulator height for stable mounting
● Gold flash plating for enhanced conductivity
● High insulation resistance (5000 MΩ Min)
● Wide operating temperature range (-40℃ to +105℃)
Product Application
● IDC cable-to-board connections
● Industrial and automation systems
● Consumer and embedded electronics
● Communication equipment
● Signal and power transmission
Name
Title
Description
Datasheet
Support
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
